Model
|
PowerEdge R760
|
|||
|
Processor
|
• Up to two 4th Generation Intel Xeon Scalable or Intel Xeon Max processors with up to 56 cores per processor and with optional Intel QuickAssist Technology • Up to two 5th Generation Intel Xeon Scalable processors with up to 64 cores per processor
|
|||
|
ذاكرة
|
• 32 DDR5 DIMM slots, supports RDIMM 8 TB max, • Speeds up to 4800 MT/s on the 4th Generation Intel Xeon Scalable or Intel Xeon
Max processors • Speeds up to 5600 MT/s on the 5th Generation Intel Xeon Scalable processors
• Supports registered ECC DDR5 DIMMs only
|
|||
|
خزن
|
• Internal Controllers: PERC H965i, PERC H755, PERC H755N, PERC H355 • External Controller: PERC H965e
• Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB
• SAS HBA (non-RAID): HBA355e, HBA355i, HBA465i
• Software RAID: S160
|
|||
|
Drive Bays
|
Front bays: • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 240 TB • Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB
• Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB
• Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) max 122.88 TB
• Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.64 TB
Rear bays:
• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
• Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB
• Up to 4 x EDSFF E3.S Gen5 NVMe (SSD) max 30.72 TB
|
|||
|
مزود الطاقة
|
• 3200 W Titanium 277 VAC or 336 HVDC, hot swap redundant • 2800 W Titanium 200—240 HLAC or 240 HVDC, hot swap redundant
• 2400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant
• 1800 W Titanium 200—240 HLAC or 240 HVDC, hot swap redundant
• 1400 W Titanium 277 VAC or 336 HVDC, hot swap redundant
• 1400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant
• 1100 W Titanium 100—240 VAC or 240 HVDC, hot swap redundant
• 1100 W -(48—60) VDC, hot swap redundant
• 800 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant
• 700 W Titanium 200—240 HLAC or 240 HVDC, hot swap redundant
|
|||
|
Size
|
• Height – 86.8 mm (3.41 inches) • Width – 482 mm (18.97 inches) • Depth – 772.13 mm (30.39 inches) with bezel 758.29 mm (29.85
inches) without bezel |
|||
|
Warranty
|
3 YEARS
|
|||
