Products Description
|
Modèle
|
|
|
Processor
|
Two Intel Xeon 6 processors, with up to 144 cores per processor
|
|
Chipset
|
N/A
|
|
Accelerators
|
Up to four single width 75 W accelerators
|
|
DIMM speed
|
Jusqu’à 6400 MT/s
|
|
Memory type
|
RDIMM
|
|
Memory module slots
|
32 DDR5 DIMM slots
|
|
Front bays
|
Jusqu’à 8 x EDSFF E3.S NVMe(SSD)
Jusqu’à 16 x EDSFF E3.S NVMe(SSD)
Jusqu’à 8 x 2.5-inch NVMe SSDs
Jusqu’à 16 x 2.5-inch SAS/SATA SSDs
|
|
Rear bays
|
N/A
|
|
Internal controllers
|
Front PERC H965i
|
|
External controllers
|
N/A
|
|
Software RAID
|
N/A
|
|
Internal boot
|
Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS): HWRAID 1, 2 x M.2 NVMe SSDs 480 GB or 960 GB or M.2
Interposer board (DC-MHS): 2 x M.2 NVMe SSDs Internal USB
|
|
System management
|
iDRAC10, iDRAC Direct, iDRAC RESTful API with Redfish
|
|
Alimentation
|
1500 W Titanium 100—240 VAC or 240 VDC
1100 W Platinum 100—240 VAC or 240 VDC
800 W Platinum 100—240 VAC or 240 VDC
|
|
Network options
|
OCP NIC card 3.0 : Jusqu’à 2 slots on the front (for front I/O configuration) ou 2 slots on the rear (for rear I/O configuration)
|
|
Front ports
|
1 x USB 2.0 Type C port (supports Host mode)
1 x USB 2.0 (optional)
1 x Mini-DisplayPort (optional)
|
|
Rear ports
|
1 x DB9 Serial
1 x Dedicated iDRAC Ethernet port
1 x VGA
2 x USB 3.1
|
|
Internal ports
|
1 x USB 3.1
|
|
PCIe
|
Jusqu’à 4 x16 Gen5 PCIe slots
|
|
Form factor
|
2Serveur rack U
|
|
Height
|
86.8 mm (3.41 inches)
|
|
Width
|
482.0 mm (18.97 inches)
|
|
Depth
|
For cold aisle (front I/O configuration):
814.52 mm (32.07 inches) without bezel For hot aisle (rear I/O configuration):
802.40 mm (31.59 inches) with bezel 801.51 mm (31.56 inches) without bezel |
|
Weight
|
28.53 Kg (62.89 lbs)
|
