Brand New DELL 24*2.5 Sff Sas/SATA/Nvme 2u Rack Server Poweredge R760

Poweredge R760

PowerEdge R760 is a 2u dual socket rack server,which supports GPUs, including two double-width Gpus or six single-width Gpus, suitable for workloads that require acceleration.PowerEdge R760 in specially built nets complex elastic mainstream server provides strong performance.

Ideal for:
• Standardize mixed workloads
• Databases and analytics
• Virtual desktop infrastructure

DELL Poweredge R760 Specs:

We accept OEM order.If you want to custom your server,please contact us and send us your configuration and budget so that we will give you competitve price and professional services.

Product name

DELL PowerEdge R760 Rack Server

Processor

• Up to two 4th Generation Intel Xeon Scalable or Intel Xeon Max processors with up to 56 cores per processor and with optional Intel® QuickAssist Technology

• Up to two 5th Generation Intel Xeon Scalable processors with up to 64 cores per processor

Memory

• 32 DDR5 DIMM slots, supports RDIMM 8 TB max,

• Speeds up to 4800 MT/s on the 4th Generation Intel Xeon Scalable or Intel XeonMax
processors
• Speeds up to 5600 MT/s on the 5th Generation Intel Xeon Scalable processors
• Supports registered ECC DDR5 DIMMs only

Storage Controllers

Internal Controllers: PERC H965i, PERC H755, PERC H755N, PERC H355

• External Controller: PERC H965e

• Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB
• SAS HBA (non-RAID): HBA355e, HBA355i, HBA465i
• Software RAID: S160

Drive Bays

Front bays:

• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 240 TB
• Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB
• Up to16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB
• Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) max 122.88 TB
• Up to 24 x 2.5-inchSAS/SATA/NVMe (HDD/SSD) max 368.64 TB

Rear bays:
• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
• Up to 4 x 2.5-inchSAS/SATA/NVMe (HDD/SSD) max 61.44 TB
• Up to 4 x EDSFF E3.S Gen5 NVMe (SSD) max 30.72 TB

Power Supply

• 3200 W Titanium 277 VAC or 336 HVDC, hot swap redundant

• 2800 W Titanium 200-240 HLAC or 240 HVDC, hot swap redundant
• 2400 W Platinum 100-240 VAC or 240 HVDC, hot swap redundant
• 1800 W Titanium 200-240 HLAC or 240 HVDC, hot swap redundant
• 1400 WTitanium 277 VAC or 336 HVDC, hot swap redundant
• 1400 W Platinum 100-240 VAC or 240 HVDC, hot swap redundant
• 1100 W Titanium100-240 VAC or 240 HVDC, hot swap redundant
• 1100 W -(48-60) VDC, hot swap redundant
• 800 W Platinum 100-240 VAC or 240 HVDC,hot swap redundant
• 700 W Titanium 200-240 HLAC or 240 HVDC, hot swap redundant
