Original brand Server PowerEdge R660 Xeon CPU
Performance, meet versatility
Where performance and density meet. More compute in less space with this dense 1U server designed for demanding workloads including artificial intelligence, database analytics and high-density virtualization.
* Add up to two 4th generation Intel® Xeon® Scalable processors with up to 56 cores for faster and more accurate processing performance
* Accelerate in-memory workloads with up to 32 DDR5 RDIMMS up to 4800 MT/sec (1DPC)
* Maximize performance with up to 3X single-wide GPUs for finishing workloads faster
* Put more data in a smaller footprint with storage options that include up to 8 x 2.5″ NVMe/SAS4/SATA, plus up to 10 x 2.5″ NVMe/SAS4/SATA
* Add up to two 4th generation Intel® Xeon® Scalable processors with up to 56 cores for faster and more accurate processing performance
* Accelerate in-memory workloads with up to 32 DDR5 RDIMMS up to 4800 MT/sec (1DPC)
* Maximize performance with up to 3X single-wide GPUs for finishing workloads faster
* Put more data in a smaller footprint with storage options that include up to 8 x 2.5″ NVMe/SAS4/SATA, plus up to 10 x 2.5″ NVMe/SAS4/SATA
|
Processor
|
Up to two 4th Generation Intel Xeon Scalable processors, with up to 56 cores and optional Intel QuickAssist Technology
|
|
Memory
|
• 32 DDR5 DIMM slots, supports RDIMM 8 TB max, speeds up to 4800 MT/s
• Supports registered ECC DDR5 DIMMs only
|
|
Storage controllers |
• Internal Controllers (RAID): PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i
• Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSD drives, or USB
• External HBAs (non-RAID): HBA355e
• Software RAID: S160
|
|
Front Ports
|
• 1 x iDRAC Direct (Micro-AB USB) port
• 1 x USB 2.0
• 1 x VGA
|
|
Mobility
|
OpenManage Mobile
|
|
Dimensions
|
• Height – 42.8 mm (1.68 inches)
• Width – 482 mm (18.97 inches)
• Depth – 822.88 mm (32.39 inches) with bezel 809.04 mm (31.85 inches) without bezel
|
|
Form Factor
|
1 U rack server
|
|
Power Supplies
|
• 1800W Titanium 200-240 VAC or 240 HVDC, hot swap with full redundant
• 1400W Platinum 100-240 VAC or 240 HVDC, hot swap with full redundant
• 1100W Titanium 100-240 VAC or 240 HVDC, hot swap with full redundant
• 1100W LVDC -48 – -60 VDC, hot swap with full redundancy
• 800W Platinum 100-240 VAC or 240 HVDC, hot swap with full redundant
• 700 W Titanium 200-240 VAC or 240 HVDC, hot swap with full redundant
|
|
Cooling Options
|
• Air cooling
• Optional Direct Liquid Cooling (DLC)
|
|
Embedded Management
|
• iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish
• iDRAC Service Module • Quick Sync 2 wireless module
|
|
Network options
|
1 x OCP card 3.0 (optional)
|
