FusionServer 5288 V5
|
|
|
Form Factor
|
4U Rack Server
|
|
Processors
|
1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205W
1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205W |
|
Memory
|
24 DDR4 DIMM slots, 2933 MT/s; up to 12 Intel® Optane™ PMem modules (100 series), 2666 MT/s
|
|
Internal Storage
|
Front:
• 24 x 3.5-inch SAS/SATA hard drives Embedded: • 4 x 3.5-inch SAS/SATA hard drives Rear: • 16 x 3.5-inch SAS/SATA hard drives • 16 x 3.5-inch SAS/SATA hard drives + 4 x 2.5-inch SAS/SATA hard drives or NVMe SSDs • 14 x 3.5-inch SAS/SATA hard drives (or 4 NVMe SSDs for the NVMe model) + 4 x 2.5-inch SAS/SATA hard drives or NVMe SSDs (this configuration does not support internal hard disk and I/O module 1) Flash storage: • Two M.2 SSDs |
|
RAID
|
RAID 0, 1, 5, 50, 6, or 60; optional supercapacitor to protect cache data from power failures; RAID level migration, drive roaming, self-diagnosis, and web-based remote configuration
|
|
Network Ports
|
• LOM: 2 x 10 GE + 2 x GE ports
• Flexible NIC: 2 x GE, 4 x GE, 2 x 10 GE, or 1/2 x 56G FDR IB ports |
|
PCIe Expansion
|
Up to 10 PCIe 3.0 slots, including 1 for a RAID controller card and 1 for a flexible NIC
|
|
Fan Modules
|
4 hot-swappable fan modules with optional N+1 redundancy
|
|
Power Supply
|
2 hot-swappable PSUs with optional 1+1 redundancy. Supported options include:
• 900W AC Platinum PSU • 1,500W AC Platinum PSU |
|
Management
|
• BMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening
• BMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports CD-free deployment and the Agentless feature, simplifying management • (Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management |
|
Certifications
|
CE, UL, FCC, CCC, and RoHS
|
|
Installation Suite
|
L-shaped guide rails, adjustable guide rails, and holding rails
|
|
Dimensions (H x W x D)
|
175 mm x 447 mm x 748 mm (6.89 in. x 17.60 in. x 29.45 in.)
|
|
Operating Temperature
|
5°C to 40°C (41°F to 104°F) (ASHRAE Class A3 compliant)
|
