Model
|
|
|
Form Factor
|
|
|
Maxim Processor
|
One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W
|
|
RAM
|
16/32 DDR4 DIMMs, up to 3,200 MT/s; 16 Optane™ PMem 200 series, up to 3,200 MT/s
|
|
Drive bays
|
Supports various drive configurations and hot swappable:
• 8-31 x 2.5-inch SAS/SATA/SSD drives • 12-20 x 3.5-inch SAS/SATA drives • 4/8/16/24 NVMe SSDs • Supports a maximum of 45 x 2.5-inch drives or 34 full-NVMe SSDs Supports flash storage: • Dual M.2 SSDs |
|
Storage controllers
|
Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level
migration, drive roaming, self-diagnosis, and remote web-based configuration |
|
I/O & Ports
|
LOM: 2 x 10GE + 2 x GE ports
|
|
Power supplies
|
• 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC)
• 1500 W AC Platinum PSUs |
|
Height X Width X Depth
|
Chassis with 3.5-inch drives: 86.1 mm x 447 mm x 790 mm
Chassis with 2.5-inch drives: 86.1 mm x 447 mm x 790 mm |
|
Rail
|
Optional rail
|
|
Weight
|
30.0kg
|
|
Management
|
BMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis,
automated O&M, and hardware security hardening |
|
Operating Temperature
|
5ºC to 45ºC (41ºF to 113ºF), and ASHRAE A3 and A4 compliant
|
|
Certifications
|
CE, UL, FCC, CCC, and RoHS
|
|
Installation Suite
|
L-shaped guide rails, adjustable guide rails, and holding rails
|
|
Dimensions (H x W x D)
|
Chassis with 3.5-inch hard drives: 86.1 mm x 447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.)
Chassis with 2.5-inch hard drives: 86.1 mm x 447 mm x 708 mm (3.39 in. x 17.60 in. x 27.87 in.) |
