Products Description
Maximum performance for your business
Maximize transformation and data-driven initiatives with extreme scale-up capabilities, for superior workload density and performance.
Maximize transformation and data-driven initiatives with extreme scale-up capabilities, for superior workload density and performance.
Spec Sheet
|
Features
|
Technical Specification
|
|||
|
Processadores
|
Up to four 4th Generation Intel Xeon Scalable processor with up to 60 cores per processor and with optional Intel® QuickAssist Technology
|
|||
|
Memória
|
• 64 Slots DIMM DDR5, supports RDIMM 16 TB máximo, speeds up to 4800 MT/s
• Supports registered ECC DDR5 DIMMs only
|
|||
|
Controladores de armazenamento
|
• Internal Controllers: PERC H965i, PERC H755, PERC H355, HBA355i
• External Controller: PERC H965e
• Internal Boot: Subsistema de armazenamento otimizado para inicialização (CHEFE-N1): TRANÇA 2 x M.2 NVMe SSDs or USB
• External HBA (não-RAID): HBA355e
• Software RAID: S160
|
|||
|
Baias de unidade
|
Front bays:
• Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) Max 122.88 TUBERCULOSE
• Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) Max 245.76 TUBERCULOSE
• Up to 24 x NVMe de 2,5 polegadas (SSD) Max 368.64 TUBERCULOSE
• Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) + 8 x NVMe de 2,5 polegadas (SSD) Max 368.64 TUBERCULOSE
• Up to 32 x 2.5-inch SAS/SATA (HDD/SSD) Max 491.52 TUBERCULOSE
• Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) Max 122.88 TUBERCULOSE
• Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) + 8 x 2.5-inch SAS/SATA (HDD/SSD) Max 245.76 TUBERCULOSE
|
|||
|
Fontes de alimentação
|
• 1100 W Titânio 100—240 VCA ou 240 HVDC, hot swap redundant
• 1400 W Platinum 100 a 240 VCA ou 240 HVDC, hot swap redundant
• 1800 W Titânio 200—240 VCA ou 240 HVDC, hot swap redundant
• 2400 W Platinum 100 a 240 VCA ou 240 HVDC, hot swap redundant
• 2800 W Titânio 200—240 VCA ou 240 HVDC, hot swap redundant
|
|||
|
Opções de resfriamento
|
• Air cooling
• Optional Direct Liquid Cooling (DLC)
* Nota: DLC is a rack solution and requires rack manifolds and a cooling
distribution unit (CDU) para operar |
|||
|
Fãs
|
• Standard (DST) fans
• Up to 6 sets (dual fan module) hot plug fans
|
|||
|
Dimension
|
• Height – 174.3 milímetro (6.86 Polegadas)
• Width – 482 milímetro (18.97 Polegadas)
• Depth – 883.195 milímetro (34.77 Polegadas) with bezel
869.195 milímetro (34.22 Polegadas) without bezel
|
|||
|
Fator de forma
|
4Servidor em rack U
|
|||
|
Embedded Management
|
• iDRAC9
• iDRAC Direct
• iDRAC RESTful API with Redfish
• iDRAC Service Module
• Quick Sync 2 wireless module
|
|||
|
Moldura
|
Moldura LCD opcional ou moldura de segurança
|
|||
|
OpenManage Software
|
• CloudIQ for PowerEdge plug in
• OpenManage Enterprise
• OpenManage Enterprise Integration for VMware vCenter
• OpenManage Integration for Microsoft System Center
• OpenManage Integration with Windows Admin Center
• OpenManage Power Manager plugin
• OpenManage Service plugin
• OpenManage Update Manager plugin
|
|||
|
Mobilidade
|
OpenManage Mobile
|
|||
|
Integrations and Connections
|
• BMC Truesight
• Microsoft System Center
• OpenManage Integration with ServiceNow
• Red Hat Ansible Modules
• Terraform Providers
• VMware vCenter and vRealize Operations Manager |
|||
|
Segurança
|
• Cryptographically signed firmware
• Data at Rest Encryption (SEDs with local or external key mgmt)
• Secure Boot
• Secure Erase
• Secured Component Verification (Hardware integrity check) • Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
|
|||
|
NIC incorporada
|
2 x 1 GbE LOM card (opcional)
|
|||
|
Opções de GPU
|
Até 4 x 400 W DW
|
|||
|
Opções de rede
|
1 x OCP card 3.0 (opcional)
Nota: The system allows either LOM card or an OCP card or both to be installed in the system
|
|||
|
Portas
|
Portas frontais
• 1 x iDRAC Direct (Micro-AB USB) port
• 1 x USB 2.0
• 1 x VGA
Portas traseiras
• 1 x Dedicated iDRAC Ethernet port
• 1 x USB 2.0
• 1 x USB 3.0
• 1 x Serial (opcional)
• 1 x VGA (opcional para configuração de resfriamento líquido direto)*
Portas internas
• 1 x USB 3.0 (opcional)
|
|||
|
Pcie
|
Up to twelve PCIe slots:
• Slot 1: 1 x16 Gen5 Full height, Half length or 1 x16 Gen5 Full height, Full length
• Slot 2: 1 x16 Gen5 Full height, Half length
• Slot 3: 1 x16 Gen5 Full height, Half length or 1 x16 Gen5 Full height, Full length (double width)
• Slot 4: 1 x16 Gen5 Low profile, Half length
• Slot 5: 1 x16 Gen5 Low profile, Half length
• Slot 6: 1 x16 Gen5 Full height, Half
length or 1 x16 Gen5 Full height, Full length (double width) • Slot 7: 1 x16 Gen5 Full height, Half length
• Slot 8: 1 x16 Gen5 Full height, Half length or 1 x16 Gen5 Full height, Full length (double width)
• Slot 9: 1 x16 Gen5 Low profile, Half length
• Slot 10: 1 x16 Gen5 Full height, Half length or 1 x16 Gen5 Full height, Full length
• Slot 11: 1 x16 Gen5 Full height, Half length or 1 x16 Gen5 Full height, Full length (double width)
• Slot 12: 1 x16 Gen5 Full height, Half length
|
|||
|
Operating System and Hypervisors
|
Canonical® Ubuntu® Server LTS
Citrix® HypervisorTM
Microsoft® Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
|
|||
