dell Me5024 2.5*24 Drive Bay 32Gb FC Port Dell ME5024 Storage Array SAS Storage

The two non-dense ME5 base arrays start at 2U and the dense ME5 array starts
at 5U. The base models all support dual-active controllers with each controller including 16GB of memory.
Optional ME5 expansion enclosures let you scale up to 336 drives or 8PB. PowerVault ME412 and ME424 expansion enclosures can only
be used with either ME5012 or ME5024 base arrays. The ME484 dense expansion enclosure is supported behind any of the ME5 base
arrays. A variety of SSD, 10K and NLSAS drives (including FIPS SEDs) are available.

  • Detalii produs
  • transportation
Product Paramenters
MODEL
Shape / Înălțime
2U rack
maximum raw capacity
Maximum support 1.53PB
Base I/O ports (per system)
4x 10Gb iSCSI (optical port)
4x 16Gb FC
Optional I/O ports (per system)
8x 16GB/32GB FC
8x 10GB/25GB iSCSI SFP
8x 12GB SAS
Maximum number of drives supported
Supports up to 192 HDDs/ SSDs
Maximum number of expansion enclosures supported
2U/12 and 2U/24: până la 7 expansions
4U/60: Până la 3 expansions
system management software
Drive encryption,
snapshot upgrades,
asynchronous mirroring
Memorie
32GB
Outer drive bay
2U, 24 drives
2U, 12 drives
4U, 60 drives
Weight
35kg
Warranty
3 years
