| [priducts name |
Hpe Proliant Dl380 Gen11 DL380G10 DL360 Gen11 DL360 Gen10 server |
| rocessor |
Поддержка 2 3Масштабируемые процессоры Intel ® Xeon ® второго поколения, each up to 40 Ядер, maximum power 270W |
| memory |
Поддерживает до 32 DDR4 DIMMs at a rate of up to 3200MT/s, RDIMMs or LRDIMMs, and the maximum capacity of a single CPU is 6TB |
| Permanent memory |
Поддерживает до 16 Intel ® Outtum ® Durable memory PMem 200 Серия (maximum capacity of 4TB for a single processor) |
| Memory controller |
The standard onboard array controller supports SATA RAID 0, 1, 10, и 5
Optional Hbas and Smart Array array cards based on dedicated slots of array cards are available
Supports NVMe Intel VROC and HPE intelligent storage SR100i
Optional Tri-mode (NVMe/SAS/SATA) HPE Smart Array controller
Optional Hardware RAID1 OS boot device with M.2 solid state Drive (NS204i-p) |
| хранение |
Поддерживает до 36 2.5-inch SATA/SAS hard drives (24 фронт + 8 внутренний + 4 rear expansion)
Поддерживает до 20 3.5-inch SATA/SAS hard disks (12 фронт + 4 внутренний + 4 rear expansion)
Поддерживает до 34 NVMe SSDS
Support for NVMe U.2, U.3, AIC, and M.2 SSDS |
| сеть |
Optional Network adapters based on standard PCIe slots
The OCP 3.0 NIC is optional |
| Слот расширения |
Three PCIe 4.0 slots are standard and up to eight PCIe 4.0 slots are supported |
| interface |
Optional front display port, optional rear VGA and serial port
5 USB 3.0 (1 фронт, 2 задний, 2 built-in), 2 optional USB 2.0; Two MicroSD cards are optional |
| GPU support |
До 8 single width GPU cards or 3 double width GPU cards |
| Optical drive |
Support external optical drive; Some models support built-in optical drives |
| управление |
iLO Standard Edition is standard. iLO Advanced Edition and OneView Advanced Edition are optional
Supports HPE iLO 5, SUM, and RESTful interface tools
Support for mobile application software APP |
| Power supply and heat dissipation |
Optional up to 1600W 1+1 hot swap redundant power supply, поддержка до 96% titanium; Supports six hot-swappable redundant fans |
| Operating temperatur |
5℃ – 45℃ |
| Case size |
87.3миллиметр(H) x 445.4mm(H) x 711.2mm(D) (2.5-inch hard disk model)
87.3миллиметр(H) x 445.4mm(H) x 743.9mm(D) (3.5-inch hard disk model) |
| warranty |
Channel sales Pre-configured (BTO) models 3 years 5 x 9 next working day response
Project sales per order configuration (CTO) models 3 years 7 x 24 x 4 hours service |
