FusionServer 2288H V7 is a new-generation 2U 2-socket rack server designed for SDS, VDI, CDN, виртуализация, big data, Баз данных,
cloud scenarios, AI inference, small enterprises, OA, and web applications, featuring low energy consumption, strong scalability,
high reliability, simplified management, and easy deployment.
Product Form
|
2U-образный стоечный сервер
|
процессор
|
1/2 fourth-generation Intel® Xeon® Scalable Processor (Sapphire Rapids), single processor supports up to 350W
|
Память
|
32 DDR5 memory slots are flexible and optional, up to 4800MT/s, support memory expansion through CXL, can expand up to 16 DDR5 or
DDR4 memory slots, and the maximum number of memory slots can reach 48* |
local storage
|
Support a variety of different hard disk configurations, hard disk supports hot swap: • Can be configured with 8-35 2.5-дюйм
SAS/SATA/SSD hard drives • Can be configured with 12-20 3.5-inch SAS/SATA hard drives • Can be configured with 4/8/16/24 NVMe SSD disks • Configurable 36*E1.s hard disk • Configurable 48*E3.s hard disk* • Support up to 45 2.5-inch hard drives, или 34 full NVMe SSDs Support Flash storage: • Dual M.2 SSDs |
RAID support
|
Optional support RAID0, 1, 10, 1E, 5, 50, 6, 60, и так далее., support Cache super capacitor protection, provide RAID level migration,
disk roaming, самодиагностика, Web remote setting and other functions |
The internet
|
Support multiple network expansion capabilities Support OCP 3.0 network card – 2 FLEX IO card slots support 2 ОКП 3.0 network
cards respectively, support on-demand configuration; support hot swap, support PCIe 5.0 |
PCIe expansion
|
До 19 PCIe expansion slots2 OCP3.0 dedicated FLEX IO expansion slots, supporting 17 standard PCIe expansion slots, включая 14
PCIe 5.0 Слоты |
GPU accelerator card
|
Поддержка 4 double-width GPU accelerator cards or 14 single-width GPU accelerator cards
|
