The Huawei 1288H V7 1U rack server utilizes a new generation of enterprise-grade hardware platform, featuring a compact design, powerful performance, and flexible expansion, making it suitable for high-density deployment scenarios.
Core Advantages
1U ultra-thin rack design saves data center space and facilitates high-density rack mounting.
Supports the new generation of Intel Xeon processors, providing powerful computing power and stable operation.
Excellent expandability; hard drives, การ์ดเครือข่าย, and RAID cards can be configured as needed.
Optimized heat dissipation and power supply ensure stable and reliable operation 24/7.
Original manufacturer architecture ensures strong compatibility and simple maintenance.
Applicable Scenarios
Enterprise virtualization, cloud computing platforms, database servers, web services, middleware, mini-program/app backends, data center hosting, distributed storage, software routers and gateways, and other business applications.
|
Product Model
|
|
|
ฟอร์มแฟคเตอร์
|
1เซิร์ฟเวอร์แร็ค U
|
|
Maxim Processor
|
1 หรือ 2 x 4th Gen Intel® Xeon® Scalable processors (แซฟไฟร์ แรพิดส์) with TDP up to 350 W per processor
|
|
RAM
|
32 x DDR5 DIMMs, with up to 4800 MT/s speed
|
|
Local Storage
|
Supports hot-swappable drives in the following configurations:
• 10 x 2.5″ drives (6–10 NVMe SSDs and 0–4 SAS/SATA drives, with a total number of 10 or less) • 10 x 2.5″ SAS/SATA drives/SSDs (2–4 NVMe SSDs and 6–8 SAS/SATA drives, with a total number of 10 or less) • 10 x 2.5″ SAS/SATA drives/SSDs • 8 x 2.5″ SAS/SATA drives/SSDs • 4 x 3.5″ SAS/SATA drives/SSDs • 32 x E1.S SSDs • 20 x E3.S SSDs* • 2 x M.2 SSDs |
|
RAID
|
Supports RAID 0, 1, 10, 5, 50, 6, หรือ 60, optional supercapacitor for cache data power failure protection, การโยกย้ายระดับ RAID,drive roaming, self-diagnosis, and remote web-based configuration
|
|
Network
|
Provides expansion capability of multiple types of networks
Supports OCP 3.0 NICs. The two FlexIO card slots support two OCP 3.0 NICs, which can be configured as required. Hot swap and PCIe 5.0 are supported |
|
PCIe Expansion
|
Provides 5 x PCIe slots, including 2 x FlexIO slots dedicated for OCP 3.0 NICs and 3 x PCIe slots, และ 2 slots support PCIe 5.0
|
|
Fan Module
|
Provides 8 x hot-swappable counter-rotating fan modules in N+1 redundancy
|
|
Power Supply
|
2 x hot-swappable PSUs in 1+1 redundancy mode. Supported options include:
• 900 W AC Platinum/Titanium PSUs (อินพุต: 100 V to 240 V AC, หรือ 192 V to 288 V DC) • 1500 W AC Platinum PSUs • 1200 W –48 V to –60 V DC PSUs (อินพุต: –38.4 V to –72 V DC) • 2000 W AC Platinum PSUs |
